BL DC SERIES Wall-mounted units in a split design with rapid release mounting couplings

  • Split air-conditioning system with quick-release mounting couplings
  • Cooling capacity: 2.70 - 3.50 kW
  • For offices and living spaces

Quick to install. Flexible to use. Reliable in operation.

The quick-connect coupling allows for easy installation of the units without having to evacuate and refill the system beforehand. The units cool, filter and dehumidify the humid room air, reliably ensuring a pleasant indoor climate even under demanding conditions. The outdoor unit can be installed individually – outside on the ground, on the wall, on the roof or alternatively in well-ventilated rooms. Thanks to the simple connection of the refrigerant line using the quick-connect coupling system, the units are very flexible in use and can be quickly relocated if necessary. In addition, the alarm contact and the external enable contact allow convenient integration into building management systems, so that fault messages can be recorded centrally and the system can be enabled or controlled externally.

  • 3D swing function with horizontal and vertical air distribution
  • "Follow me" function for temperature reconciliation between unit and remote controller
  • USB interface for Smart-Control WiFi stick
  • Frost protection function - heating with set value of 8°C
  • Floating contacts for external start/stop and alarm forwarding
  • Pre-filled refrigerant lines available in lengths of 3, 5 or 8 metres
Easy mounting due to separately available connection set
Easy mounting due to separately available connection set
Icon Amazon Alexa Kompatiblität

Per Alexa controllable – thanks to the Smart-Control WiFi stick

With Amazon Alexa compatibility, operation becomes even easier: key functions can be controlled conveniently by voice command and seamlessly integrated into existing smart home routines – for greater comfort and control.


Technical data

VariantBL 265 DCBL 355 DC
Cooling capacity 2.7 (0.9-3.4) kW 3.5 (2.1-4.0) kW
Energy efficiency rating for cooling A++ A++
Energy efficiency ratio SEER 6.8 6.3
Power consumption annual, cooling, QCE 200 kWh 200 kWh
Room cooling annual utilisation factor ηs,c 269 % 249 %
